Hot air circulation oven
Product description
This RXH Hot air circulation oven is used for heating and curing, drying and dewatering of materials in medicine, chemical industry, food, agricultural and sideline products, aquatic products, light industry and other industries.Such as raw materials, Chinese medicine medicinal slices, extract, powder, granule, dehydrated vegetables and so on .
Working principle
The hot air circulation oven air circulation system adopts the fan circulation air supply mode, the air circulation is uniform and efficient.The air source is driven by the circulating air supply motor (with no contact switch) through the heater, and the hot air is sent out, and then through the air duct to the oven, and then the air after use is inhaled into the air duct to become the air source again for heating.Ensure indoor temperature uniformity.When the temperature value swings due to the opening and closing action, the air supply circulation system quickly returns to the operating state until the set temperature value is reached.
The heating element is controlled by a temperature controller.
| Parameters of RXH series hot air circulation oven | ||||||||||
|
TYPE |
Drying area（㎡） |
Amount of drying（kg/batch） |
heating power（kw） |
blower power（kw） |
temperature difference in the oven（℃） |
numbers of tray（PCS） |
draying cart |
size（mm） |
weight(kg) |
remark |
|
RXH-2-C |
2 |
10 |
6 |
0.45 |
±2 |
6 |
0 |
1000*860*1260 | 350 | singel door |
|
RXH-4-C |
4 |
20 |
8 |
0.45 |
±2 |
12 |
0 |
1000*860*1260 | 400 | singel door |
|
RXH-5-C |
5 |
25 |
8 |
0.45 |
±2 |
16 |
0 |
1500*1000*2044 | 480 | singel door |
|
RXH-7-C |
7 |
60 |
9 |
0.45 |
±2 |
24 |
1 |
1500*1300*2100 | 800 | singel door |
|
RXH-14-C |
14 |
120 |
15 |
0.45 |
±2 |
48 |
2 |
2400*1300*2100 | 1050 | double doors |
|
RXH-27-C |
27 |
240 |
30 |
0.45*2 |
±2 |
96 |
4 |
2250*2500*2160 | 1100 | double doors |
|
RXH-41-C |
41 |
360 |
45 |
0.45*3 |
±2 |
144 |
6 |
3200*2260*2000 | 1950 | double doors |
|
RXH-54-C |
54 |
480 |
60 |
0.45*4 |
±2 |
192 |
8 |
4360*2160*2000 | 2380 | double doors |
Feature
1, hot air circulation in the oven, high thermal efficiency, energy saving.
2. The oven is equipped with air duct by means of forced ventilation to ensure even drying of materials.
3. The oven runs smoothly.Automatic temperature control, easy installation and maintenance.
4. wide range of application, can dry all kinds of materials, is an ideal general drying equipment
